Carbon Fiber Paint/Water-Based One-Component Paint

Carbon Fiber Paint/Water-Based One-Component Paint

TQ-XXX
Made of environmentally friendly materials such as nano-level water-based acrylic resin, the paint film has high hardness, good adhesion, good weather resistance and water resistance, and is suitable for products with high requirements for decorative effects.

Consult

Features Technical Indicators Overall Dimension

Product introduction: Made of environmentally friendly materials such as water-based amino resin and water-based acrylic resin, the paint film has high hardness, good adhesion and good weather resistance, and is suitable for products with high requirements for decorative effects.
Product characteristics: The coating film dries quickly, has little odor, is cost-effective, has good fullness of the paint film, good aging resistance, and strong decorative effect.
Instructions for use:
Product preparation: First stir the additive evenly, then add pure water.
Coating method: air spraying

Spraying parameters	Spray gun caliber	Spraying pressure	Dilution ratio	Construction viscosity
Air spray	1.8		10:1	28-32s（T4#/25℃）

Spraying environment temperature: 5-40℃, the surface temperature of the sprayed object must be higher than the dew point by more than 3℃.
Spraying environment air humidity: <80%
Application areas: carbon fiber, automotive interior. Particularly suitable for home appliances, automotive accessories and other fields with strict restrictions on appearance and VOC.

Test items	Performance Indicators
Viscosity	75-85 seconds (T4#/25℃)/85-90KU(KU/25℃)
Adhesion	≤1 level
Hardness	≥HB
Luster	20-30°
Water resistance	120H no blistering, no peeling
Solid	40-45% (different colors may vary)
Impact resistance	≥80cm
Density	1.15-1.25g/ml
