High Temperature Resistant Ceramic Coating One Component

High Temperature Resistant Ceramic Coating One Component

GW-W-XXXX
The product film has high hardness, good flexibility and adhesion, heat resistance, wear resistance, corrosion resistance, water resistance, chemical resistance, environmental protection and non-toxicity. It is widely used in surface finishing of kitchen utensils, boilers, barbecue stoves, engines, etc.

Consult

Features Technical Indicators Overall Dimension

Product introduction: High temperature resistant single component ceramic coating, made of high quality inorganic silicone resin and organic silicone composite, refined by advanced formula process.
Product characteristics: The paint film has high hardness, good flexibility and adhesion, heat resistance, wear resistance, corrosion resistance, rust resistance, water resistance, chemical resistance, environmental protection and non-toxicity.
Instructions for use:
Pre-treatment: Use alcohol to remove grease, dust and particles on the surface of the material.
Painting: Stir evenly with a tumbler, filter with a 200-300 mesh filter and spray directly. Preheat the material to 70℃*2min before spraying and the paint film effect is better.
Drying: Low temperature 90℃×10 minutes, high temperature 220℃×30 minutes before going offline.
Spraying distance: 15~25cm
Film thickness: 15±3um
Spraying gun method: cross 2~4 times
Cleaning agent: ethanol
Application field: widely used in surface finishing of kitchenware, boilers, barbecue stoves, engines, etc.

Serial number	Project	Standard National Standard	Indicators Technical Parameters
1	Adhesion	GB/T 9286-88	Level 0 (sandblasted aluminum plate)
2	Wear resistance	RCA Tape Machine Test	≥300 times
3	Fineness (um)	≤40	≤30
4	Hardness	GB/T 6739-86	No shedding, no changes
5	Temperature resistance	Temperature resistance below 300℃	No shedding, no changes
6	Impact resistance	30cm*1kg	30cm*1kg forward pass
7	Luster	Photometer	Can be customized according to customer needs
The selected pigment type complies with ASTM F963-96T and EN71: part3:1994 standards
